NR-IRDL0114-8-27K Series
POWER (WATT)
8.0
IP RATING
IP20
CCT
2700K
BEAM ANGLE
36°
Ra
90
Technical Specifications Basic Parameters
Model No
NR-IRDL0114-8-27K Series
Category
LED Downlight
Installation Methods
Recessed
Classes of Electrical Protection
Class II
IP Rating
IP20
ta
40°C
Input Voltage
AC220-240V
Frequency
Hz
Type of Chips
COB
Watt
8.0
lm/w
65.0
Useful Lumen
520.0
CCT
2700K
Beam Angle
36°
Ra
90
PF
0.5
DF
0.7
Body Color
Black/White
Product Main Material
Aluminum
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Φ45
Guarantee
3
Directionality
Direct
Product Size (mm)
Φ52*86
Energy efficiency QR included
Model Variants 4 beam options
| New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NR-IRDL0114-8-27K-BK-36D | LED Downlight | Recessed | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 8.0 | 65.0 | 520.0 | 2700K | 36° | 90 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | Φ45 | 3 | Direct | Φ52*86 |
| NR-IRDL0114-8-27K-WH-36D | LED Downlight | Recessed | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 8.0 | 65.0 | 520.0 | 2700K | 36° | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ45 | 3 | Direct | Φ52*86 |
Resources & Downloads Technical files
