NRP-DL104S Series
POWER (WATT)
10.0/20.0/30.0/40.0
IP RATING
IP20
CCT
3000K
BEAM ANGLE
20°
Ra
97
Technical Specifications Basic Parameters
Model No
NRP-DL104S Series
Category
Surface Mounted Downlight
Installation Methods
Surface Mounted
Classes of Electrical Protection
Class II+III
IP Rating
IP20
ta
40°C
Input Voltage
AC220-240V
Frequency
Hz
Type of Chips
COB
Watt
10.0/20.0/30.0/40.0
lm/w
68.0/80/74/74.0
Useful Lumen
680.0/1600/2220/2960.0
CCT
3000K
Beam Angle
20°
Ra
97
PF
0.5/0.7/0.9
DF
0.7/0.9
Body Color
Black/White
Product Main Material
Aluminum
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Guarantee
5
Directionality
Direct
Product Size (mm)
117*117*56/227*117*56/332*117*56/227*227*56
Energy efficiency QR included
Model Variants 4 beam options
| New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NRP-SDL0101-10-30K-BK-20D | Surface Mounted Downlight | Surface Mounted | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 10.0 | 68.0 | 680.0 | 3000K | 20° | 97 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 117*117*56 |
| NRP-SDL0101-10-30K-WH-20D | Surface Mounted Downlight | Surface Mounted | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 10.0 | 68.0 | 680.0 | 3000K | 20° | 97 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 117*117*56 |
| NRP-SDL0101-20-30K-BK-20D | Surface Mounted Downlight | Surface Mounted | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 20.0 | 80 | 1600 | 3000K | 20° | 97 | 0.7 | 0.7 | Black | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 227*117*56 |
| NR-DL104S-20 WW | Surface Mounted Downlight | Surface Mounted | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 20.0 | 80 | 1600 | 3000K | 20° | 97 | 0.7 | 0.7 | White | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 227*117*56 |
| NRP-SDL0101-30-30K-BK-20D | Surface Mounted Downlight | Surface Mounted | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 74 | 2220 | 3000K | 20° | 97 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 332*117*56 |
| NR-DL104S-30 WW | Surface Mounted Downlight | Surface Mounted | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 74 | 2220 | 3000K | 20° | 97 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 332*117*56 |
| NRP-SDL0101-40-30K-BK-20D | Surface Mounted Downlight | Surface Mounted | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 40.0 | 74.0 | 2960.0 | 3000K | 20° | 97 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 227*227*56 |
| NRP-SDL0101-40-30K-WH-20D | Surface Mounted Downlight | Surface Mounted | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 40.0 | 74.0 | 2960.0 | 3000K | 20° | 97 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 227*227*56 |
