CP7024
POWER (WATT)
2.0
IP RATING
IP67
CCT
3000K
BEAM ANGLE
180°/90°
Ra
80
Technical Specifications Basic Parameters
Model No
CP7024-1/CP7024-2/CP7024-3
New Model No
NR-BL0351-2/NR-BL0401-2/NR-BL0451-2
Category
LED Outdoor Buried Lamp
Installation Methods
Recessed
Classes of Electrical Protection
Class III
IP Rating
IP67
ta
50°C
Input Voltage
DC24V
Frequency
Type of Chips
SMD
Watt
2.0
lm/w
15.0
Useful Lumen
30.0
CCT
3000K
Beam Angle
180°/90°
Ra
80
PF
1.0
DF
1.0
Body Color
Silver
Product Main Material
PP
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Φ50
Guarantee
3
Directionality
Indirect
Product Size (mm)
Φ51.5*91
Energy efficiency QR included
Model Variants 4 beam options
| Item Code | New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CP7024-1 | NR-BL0351-2 | LED Outdoor Buried Lamp | Recessed | Class III | IP67 | 50°C | DC24V | N/A | SMD | 2.0 | 15.0 | 30.0 | 3000K | 180° | 80 | 1.0 | 1.0 | Silver | PP | Non-Adjustable Light | Φ50 | 3 | Indirect | Φ51.5*91 |
| CP7024-2 | NR-BL0401-2 | LED Outdoor Buried Lamp | Recessed | Class III | IP67 | 50°C | DC24V | N/A | SMD | 2.0 | 15.0 | 30.0 | 3000K | 180° | 80 | 1.0 | 1.0 | Silver | PP | Non-Adjustable Light | Φ50 | 3 | Indirect | Φ51.5*91 |
| CP7024-3 | NR-BL0451-2 | LED Outdoor Buried Lamp | Recessed | Class III | IP67 | 50°C | DC24V | N/A | SMD | 2.0 | 15.0 | 30.0 | 3000K | 90° | 80 | 1.0 | 1.0 | Silver | PP | Non-Adjustable Light | Φ50 | 3 | Indirect | Φ51.5*91 |
