CP7027-120 Series
POWER (WATT)
6.0
IP RATING
IP67
CCT
3000K
BEAM ANGLE
100°/24°/15°
Ra
80
Technical Specifications Basic Parameters
Model No
CP7027-120 Series
New Model No
NR-BL0203-6-30K-SL-100D/NR-BL0201-6-30K-SL-24D/NR-BL0202-6-30K-SL-15D
Category
LED Outdoor Buried Lamp
Installation Methods
Recessed
Classes of Electrical Protection
Class I
IP Rating
IP67
ta
50°C
Input Voltage
AC220-240V
Frequency
Hz
Type of Chips
SMD
Watt
6.0
lm/w
5.0
Useful Lumen
30.0
CCT
3000K
Beam Angle
100°/24°/15°
Ra
80
PF
0.5
DF
0.7
Body Color
Black
Product Main Material
Aluminum
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Φ120
Guarantee
3
Directionality
Direct
Product Size (mm)
Φ120*100
Column 26
Column 27
Energy efficiency QR included
Model Variants 4 beam options
| Item Code | New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CP7027-120-1 | NR-BL0203-6-30K-SL-100D | LED Outdoor Buried Lamp | Recessed | Class I | IP67 | 50°C | AC220-240V | Hz | SMD | 6.0 | 5.0 | 30.0 | 3000K | 100° | 80 | 0.5 | 0.7 | Aluminum | Non-Adjustable Light | Φ120 | 3 | Direct | Φ120*100 | |||
| CP7027-120-2 | NR-BL0201-6-30K-SL-24D | LED Outdoor Buried Lamp | Recessed | Class I | IP67 | 50°C | AC220-240V | Hz | SMD | 6.0 | 5.0 | 30.0 | 3000K | 24° | 80 | 0.5 | 0.7 | Aluminum | Non-Adjustable Light | Φ120 | 3 | Direct | Φ120*100 | |||
| CP7027-120-4 | NR-BL0202-6-30K-SL-15D | LED Outdoor Buried Lamp | Recessed | Class I | IP67 | 50°C | AC220-240V | Hz | SMD | 6.0 | 5.0 | 30.0 | 3000K | 15° | 80 | 0.5 | 0.7 | Aluminum | Non-Adjustable Light | Φ120 | 3 | Direct | Φ120*100 |
