NR-BL0101 Series
POWER (WATT)
3.0/7.0/15.0/24.0
IP RATING
IP67
CCT
3000K
BEAM ANGLE
30°/12°
Ra
80
Technical Specifications Basic Parameters
Model No
NR-BL0101 Series
Category
LED Outdoor Buried Lamp
Installation Methods
Recessed
Classes of Electrical Protection
Class I
IP Rating
IP67
ta
50°C
Input Voltage
AC220-240V
Frequency
Hz
Type of Chips
SMD
Watt
3.0/7.0/15.0/24.0
lm/w
65.0/77.0/95.0/71.0/74.0
Useful Lumen
195.0/539.0/665.0/1065.0/1776.0
CCT
3000K
Beam Angle
30°/12°
Ra
80
PF
0.5
DF
0.4/0.5/0.7
Body Color
Silver/Black
Product Main Material
PP
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Φ76/Φ115/Φ175/Φ193
Guarantee
3
Directionality
Direct
Product Size (mm)
Φ90*75/Φ120*87/Φ180*87/Φ200*87
Energy efficiency QR included
Model Variants 4 beam options
| New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NR-BL0101-3-30K-SL-30D | LED Outdoor Buried Lamp | Recessed | Class I | IP67 | 50°C | AC220-240V | Hz | SMD | 3.0 | 65.0 | 195.0 | 3000K | 30° | 80 | 0.5 | 0.4 | Silver | PP | Non-Adjustable Light | Φ76 | 3 | Direct | Φ90*75 |
| NR-BL0101-3-30K-BK-30D | LED Outdoor Buried Lamp | Recessed | Class I | IP67 | 50°C | AC220-240V | Hz | SMD | 3.0 | 65.0 | 195.0 | 3000K | 30° | 80 | 0.5 | 0.4 | Black | PP | Non-Adjustable Light | Φ76 | 3 | Direct | Φ90*75 |
| NR-BL0101-7-30K-SL-30D | LED Outdoor Buried Lamp | Recessed | Class I | IP67 | 50°C | AC220-240V | Hz | SMD | 7.0 | 77.0 | 539.0 | 3000K | 30° | 80 | 0.5 | 0.5 | Silver | PP | Non-Adjustable Light | Φ115 | 3 | Direct | Φ120*87 |
| NR-BL0101-7-30K-SL-12D | LED Outdoor Buried Lamp | Recessed | Class I | IP67 | 50°C | AC220-240V | Hz | SMD | 7.0 | 95.0 | 665.0 | 3000K | 12° | 80 | 0.5 | 0.7 | Silver | PP | Non-Adjustable Light | Φ115 | 3 | Direct | Φ120*87 |
| NR-BL0101-15-30K-SL-30D | LED Outdoor Buried Lamp | Recessed | Class I | IP67 | 50°C | AC220-240V | Hz | SMD | 15.0 | 71.0 | 1065.0 | 3000K | 30° | 80 | 0.5 | 0.7 | Silver | PP | Non-Adjustable Light | Φ175 | 3 | Direct | Φ180*87 |
| NR-BL0101-24-30K-SL-30D | LED Outdoor Buried Lamp | Recessed | Class I | IP67 | 50°C | AC220-240V | Hz | SMD | 24.0 | 74.0 | 1776.0 | 3000K | 30° | 80 | 0.5 | 0.5 | Silver | PP | Non-Adjustable Light | Φ193 | 3 | Direct | Φ200*87 |
| NR-BL0101-24-30K-SL-12D | LED Outdoor Buried Lamp | Recessed | Class I | IP67 | 50°C | AC220-240V | Hz | SMD | 24.0 | 74.0 | 1776.0 | 3000K | 12° | 80 | 0.5 | 0.7 | Silver | PP | Non-Adjustable Light | Φ193 | 3 | Direct | Φ200*87 |
